In order to satisfy the high precision cutter head system developed by the whole process method of contour gear, the cutter mounting method is fast and convenient, and the tool mounting accuracy is +/-0.0025mm. With the latest development of gear processing closed-loop system, it can meet the processing requirements of multi-varieties and multi-working conditions.

1. Whole Processing, High Efficiency

2. Meet the requirements of dry and wet cutting

3. The inclination angle of multi-angle cutter head can be adapted to two or three-sided cutter blades.

4. Cutter head radius 76-200 mm

5. Optional coated carbide and high speed steel blades

6. Applicable to all models.

技术亮点
技术参数
加工视频

CYCON Cutter Series：

Two Sides CYCON Cutter:

Cutter Radius	Model	Numbers of Cutter	Blade Size （mm×mm）
51	CYCON-7-51-12-L/R-A/B-2F	7	12.7×10.16
	CYCON-11-51-12-L/R-A/B-2F	11	9×7.5
64	CYCON-11-64-12-L/R-A/B-2F	11	12.7×10.16
	CYCON-13-64-12-L/R-A/B-2F	13	9×7.5
76	CYCON-13-76-12-L/R-A/B-2F	13	12.7×10.16
	CYCON-17-76-12-L/R-A/B-2F	17	9×7.5
88	CYCON-11-88-22-L/R-A/B-2F	11	15.24×15.24
	CYCON-17-88-12-L/R-A/B-2F	17	12.7×10.16
	CYCON-19-88-12-L/R-A/B-2F	19	9×7.5
105	CYCON-13-105-22-L/R-A/B-2F	13	15.24×15.24
	CYCON-19-105-12-L/R-A/B-2F	19	12.7×10.16
125	CYCON-13-125-22-L/R-A/B-2F	13	19.685×15.24
	CYCON-17-125-12-L/R-A/B-2F	17	22.86×14.732
150	CYCON-17-150-22-L/R-A/B-2F	17	19.685×15.24
	CYCON-19-150-22-L/R-A/B-2F	19	17×13.5
175	CYCON-17-175-22-L/R-A/B-2F	17	19.685×15.24
	CYCON-19-175-22-L/R-A/B-2F	19	19.685×15.24
200	CYCON-17-200-22-L/R-A/B-2F	17	19.685×15.24

Three Sides CYCON Cutter:

Cutter Radius	Model	Numbers of Cutter	Blade Size （mm×mm）
51	CYCON-7-51-12-L/R-A/B-3F	7	12.7×10.16
51	CYCON-11-51-12-L/R-A/B-3F	11	9×7.5
64	CYCON-11-64-12-L/R-A/B--3F	11	12.7×10.16
64	CYCON-13-64-12-L/R-A/B--3F	13	9×7.5
76	CYCON-13-76-12-L/R-A/B--3F	13	12.7×10.16
76	CYCON-17-76-12-L/R-A/B--3F	17	9×7.5
88	CYCON-11-88-22-L/R-A/B-3F	11	15.24×15.24
	CYCON-17-88-12-L/R-A/B-3F	17	12.7×10.16
	CYCON-19-88-12-L/R-A/B-3F	19	9×7.5
105	CYCON-13-105-22-L/R-A/B-3F	13	15.24×15.24
105	CYCON-19-105-12-L/R-A/B-3F	19	12.7×10.16
125	CYCON-13-125-22-L/R-A/B-3F	13	19.685×15.24
125	CYCON-17-125-12-L/R-A/B-3F	17	22.86×14.732
150	CYCON-17-150-22-L/R-A/B-3F	17	19.685×15.24
150	CYCON-19-150-22-L/R-A/B-3F	19	17×13.5
175	CYCON-17-175-22-L/R-A/B-3F	17	22.86×14.732
175	CYCON-19-175-22-L/R-A/B-3F	19	19.685×15.24
200	CYCON-17-200-22-L/R-A/B-3F	17	19.685×15.24

CYARC Cutter Series：

Two Sides CYARC Cutter:

Cutter Size	Model	Numbers of Cutter	Blade Size （mm×mm）
1.75″	CYARC-6-1.75＂-12-L/R-A/B-2F	6	9×5
2.5″	CYARC-9-2.5＂-12-L/R-A/B-2F	9	9×5
3.25″	CYARC-9-3.25＂-12-L/R-A/B-2F	9	12.7×7.5
3.75″	CYARC-9-3.75＂-12-L/R-A/B-2F	9	12.7×7.5
4.375″	CYARC-11-4.375＂-12-L/R-A/B-2F	11	12.7×7.5
5″	CYARC-11-5＂-12-L/R-A/B-2F	11	15.24×10.16
6″	CYARC-14-6＂-12-L/R-A/B-2F	14	15.24×10.16
7.5″	CYARC-16-7.5＂-22-L/R-A/B-2F	16	15.24×10.16
9″	CYARC-17-9＂-22-L/R-A/B-2F	17	21.59×12.7
10.5″	CYARC-18-10.5＂-22-L/R-A/B-2F	18	21.59×12.7
12″	CYARC-20-12＂-22-L/R-A/B-2F	20	22.86×14.732
14″	CYARC-20-14＂-22-L/R-A/B-2F	20	22.86×14.732
16″	CYARC-26-16＂-22-L/R-A/B-2F	26	22.86×14.732
18″	CYARC-28-18＂-22-L/R-A/B-2F	28	22.86×14.732

Three Sides CYARC Cutter:

Cutter Size	Model	Numbers of Cutter	Blade Size （mm×mm）
1.75″	CYARC-6-1.75＂-12-L/R-A/B-3F	6	9×5
2.5″	CYARC-9-2.5＂-12-L/R-A/B-3F	9	9×5
3.25″	CYARC-9-3.25＂-12-L/R-A/B-3F	9	12.7×7.5
3.75″	CYARC-9-3.75＂-12-L/R-A/B-3F	9	12.7×7.5
4.375″	CYARC-11-4.375＂-12-L/R-A/B-3F	11	12.7×7.5
5″	CYARC-11-5＂-12-L/R-A/B-3F	11	15.24×10.16
6″	CYARC-14-6＂-12-L/R-A/B-3F	14	15.24×10.16
7.5″	CYARC-16-7.5＂-22-L/R-A/B-3F	16	15.24×10.16
9″	CYARC-17-9＂-22-L/R-A/B-3F	17	21.59×12.7
10.5″	CYARC-18-10.5＂-22-L/R-A/B-3F	18	21.59×12.7
12″	CYARC-20-12＂-22-L/R-A/B-3F	20	22.86×14.732
14″	CYARC-20-14＂-22-L/R-A/B-3F	20	22.86×14.732
16″	CYARC-26-16＂-22-L/R-A/B-3F	26	22.86×14.732
18″	CYARC-28-18＂-22-L/R-A/B-3F	28	22.86×14.732
